We represent MAURER SÖHNE in Mexico.  We also use DEL technology:
|
Pot bearings
Pot, Spherical and linear-Rocker bearings, up to 5000 Mton capacity
TGa Multidirectional bearings
sThese bearings are used for movements in both ways. “x” and “y” direction. They are able to resist and transmit external horizontal forces like seism.
TGe Unidirectional bearings
This kind of bearings are used for just one direction movements. They are capable to resist and transmit forces on the direction the movement is restricted.
TF Fixed bearings
The fixed bearings does not allow any movement: They are are used to transmit horizontal forces in any direction.
 |
 |
 |
Elastomeric Pads
Laminated bearings may be molded to any shape or size depending on the design requirements. Internal steel plates may vary in thickness and are vulcanized-bonded during the molding process.
The pads fulfill all AASHTO specifications: the compression and the low temperature resistance, the adhesion and the deflection.
Product presentation: bonded to load plates, rectangular, circular, beveled, clipped cornes and skewed.
Material specifications
| Concept | Norm | Requirements |
Physical Characteristics
|
ASTM D2240 ASTM D412 ASTM D412 |
60 + 5 2500 350 |
Oven aging, 70h at 212 °F (100°C)
|
ASTM D573 ASTM D573 ASTM D573 ASTM D573 |
OA + 15 - 15 - 40 |
Compresion
|
ASTM D395 (B) |
35 |
Ozone resistance
|
ASTM D1149 |
No cracks |
Low temperature recovery
|
ASTM D746 Method B |
No cracks |
Adhesion
|
ASTM D429 (B) |
40 |
Compression-deflection properties
|
ASTM D575 |
